Features
• 100 - 240VAC Universal Input
• LPS Compliance
• Protections:
• Short Circuit / Open voltage / Over Current
• Energy Efficiency Level VI or CoC Tier II
• No Load Power Consumption
CEC level VI: ≤ 0.1W
CoC Tier II: ≤ 0.075W
• MTBF > 100,000 hours
HA1024 X
X:Output voltage range
| MODEL No. | MAX. OUTPUT POWER | OUTPUT VOLTAGE | MIN. | MAX. | LOAD REGULATION | LINE REGULATION | RIPPLE & NOISE |
| LOAD | LOAD | ||||||
| HA1024A | 12W | 8-13V | 0A | 1A | ± 5% | ± 1% | 180mV |
| HA1024B | 15W | 8-13V | 0A | 1.25A | ± 5% | ± 1% | 180mV |
| HA1024C | 20W | 8-13V | 0A | 1.66A | ± 5% | ± 1% | 180mV |
| HA1024D | 24W | 8-13V | 0A | 2A | ± 5% | ± 1% | 180mV |
| HA1024E | 12W | 12V | 0A | 1A | ± 5% | ± 1% | 180mV |
| HA1024F | 24W | 12V | 0A | 2A | ± 5% | ±1% | 180mV |
NOTE:
1 : Ripple & Noise is measured by using 20MHz bandwidth limited oscilloscope and terminated each output with a 0.1uF ceramic capacitor & parallel with 47uF aluminum capacitor at full load and nominal line.
2 : Line regulation is defined by changing ±10% of input voltage from nominal line at rated load.
3 : Max. Power (W) >=Vo x Io
Electrical Specification
INPUT
• Input Range 100 to 240 VAC
• Frequency 50 to 60Hz
• Input Current <=1.0A
• Inrush Current 30A/100VAC 60A/230VAC
• Hold Up Time ≥8.3ms
• Turn On Time <=3s
OUTPUT
•Over Voltage Protection Auto Recovery
•Short Circuit Protection Auto Recovery
•Over Current Protection Auto Recovery
ENVIRONMENTAL
•Operating Temperature 0 to 40°C
•Storage Temperature -20 to 85°C
•Operation Humidity 10% to 90 %
•Storage Humidity 5% to 95 %
SAFETY
• Certified for the whole series: UL 62368-1
• Certified for the assigned models: CCC
Mechanical Specification
• Case Size: 70L x 30W x 40H(mm)
• AC Inlet: C8
• Weight: 120 +/-10g
A universal AC-DC adapter is a great way to save money and space when traveling. With this handy device, you can use one charger for all your electronic devices that require a USB connection. This includes phones, tablets, e-readers, and more. The Plug v2 is a great option for those looking for a reliable and affordable universal AC-DC adapter.
This adapter comes with two USB ports, so you can charge multiple devices at the same time. It also features an LED indicator so you know when it's plugged in and charging. The Plug v2 is compatible with most major brands of phones and tablets, making it a versatile choice for travelers.
If you're looking for a universal AC-DC adapter that won't break the bank, the Plug v2 is a great option. With its two USB ports and LED indicator, it's a convenient and easy way to keep all your devices charged while on the go.
The product advantage of the Plug v Universal AC DC-DC Adapter is its compatibility. The adapter can be used with any device that has a 3.5mm or 2.5mm input, making it the perfect accessory for anyone who owns multiple devices. It also includes an LED indicator so you know when it's properly plugged in.
A plug v a universal AC DC-DC adapter can be used for a variety of purposes. The most common use is to charge electronic devices, such as cell phones, laptops, and tablets. The adapter can also be used to power small appliances, such as lamps and fans. Additionally, the adapter can be used to jump start a car or motorcycle.
Features
• 100 - 240VAC Universal Input
• LPS Compliance
• Protections:
• Short Circuit / Open voltage / Over Current
• Energy Efficiency Level VI or CoC Tier II
• No Load Power Consumption
CEC level VI: ≤ 0.1W
CoC Tier II: ≤ 0.075W
• MTBF > 100,000 hours
HA1024 X
X:Output voltage range
| MODEL No. | MAX. OUTPUT POWER | OUTPUT VOLTAGE | MIN. | MAX. | LOAD REGULATION | LINE REGULATION | RIPPLE & NOISE |
| LOAD | LOAD | ||||||
| HA1024A | 12W | 8-13V | 0A | 1A | ± 5% | ± 1% | 180mV |
| HA1024B | 15W | 8-13V | 0A | 1.25A | ± 5% | ± 1% | 180mV |
| HA1024C | 20W | 8-13V | 0A | 1.66A | ± 5% | ± 1% | 180mV |
| HA1024D | 24W | 8-13V | 0A | 2A | ± 5% | ± 1% | 180mV |
| HA1024E | 12W | 12V | 0A | 1A | ± 5% | ± 1% | 180mV |
| HA1024F | 24W | 12V | 0A | 2A | ± 5% | ±1% | 180mV |
NOTE:
1 : Ripple & Noise is measured by using 20MHz bandwidth limited oscilloscope and terminated each output with a 0.1uF ceramic capacitor & parallel with 47uF aluminum capacitor at full load and nominal line.
2 : Line regulation is defined by changing ±10% of input voltage from nominal line at rated load.
3 : Max. Power (W) >=Vo x Io
Electrical Specification
INPUT
• Input Range 100 to 240 VAC
• Frequency 50 to 60Hz
• Input Current <=1.0A
• Inrush Current 30A/100VAC 60A/230VAC
• Hold Up Time ≥8.3ms
• Turn On Time <=3s
OUTPUT
•Over Voltage Protection Auto Recovery
•Short Circuit Protection Auto Recovery
•Over Current Protection Auto Recovery
ENVIRONMENTAL
•Operating Temperature 0 to 40°C
•Storage Temperature -20 to 85°C
•Operation Humidity 10% to 90 %
•Storage Humidity 5% to 95 %
SAFETY
• Certified for the whole series: UL 62368-1
• Certified for the assigned models: CCC
Mechanical Specification
• Case Size: 70L x 30W x 40H(mm)
• AC Inlet: C8
• Weight: 120 +/-10g
A universal AC-DC adapter is a great way to save money and space when traveling. With this handy device, you can use one charger for all your electronic devices that require a USB connection. This includes phones, tablets, e-readers, and more. The Plug v2 is a great option for those looking for a reliable and affordable universal AC-DC adapter.
This adapter comes with two USB ports, so you can charge multiple devices at the same time. It also features an LED indicator so you know when it's plugged in and charging. The Plug v2 is compatible with most major brands of phones and tablets, making it a versatile choice for travelers.
If you're looking for a universal AC-DC adapter that won't break the bank, the Plug v2 is a great option. With its two USB ports and LED indicator, it's a convenient and easy way to keep all your devices charged while on the go.
The product advantage of the Plug v Universal AC DC-DC Adapter is its compatibility. The adapter can be used with any device that has a 3.5mm or 2.5mm input, making it the perfect accessory for anyone who owns multiple devices. It also includes an LED indicator so you know when it's properly plugged in.
A plug v a universal AC DC-DC adapter can be used for a variety of purposes. The most common use is to charge electronic devices, such as cell phones, laptops, and tablets. The adapter can also be used to power small appliances, such as lamps and fans. Additionally, the adapter can be used to jump start a car or motorcycle.
